PTT over Cellular Radio

The Hytera PNC380S PoC device is a compact, rugged, and easy-to-operate handheld device that utilizes Wi-Fi and existing nationwide 3G/4G/LTE cellular networks for unlimited coverage and capacity. The PNC380S is designed for reliable business communications with instant group calling in the vehicle and on the job site. It can be quickly deployed without the significant infrastructure costs of traditional radio systems.

  • Nationwide coverage with 3G/4G/LTE and Wi-Fi networks
  • Supports dispatching, group calling, and location tracking Instant group voice, video, and text communications
  • Easy-to-use, compact and rugged device
  • Car Kit option for mounting in vehicles

The PNC380S is part of the Hytera HALO Nationwide Group Communications Solution that enables Push-to-Talk over Cellular over existing 3G/4G/LTE Mobile Network Operator infrastructure and Wi-Fi networks.

EMERGENCY BUTTON

5

TFT LCD DISPLAY

5

MENU NAVIGATION

5

FULL KEYPAD

5

CLEAR AUDIO

5

Volume

5

8 MEGALPIXEL CAMERA

5

FLASHLIGHT

5

LONG-LIFE BATTERY

5

USB DATA/CHARGING PORT

5

BUILT-IN GPS

5

PROGRAMMABLE BUTTON

5

PUSH-TO-TALK

5

VOLUME CONTROL

5

MIL-STD & IP67 RATED

5

Functions

INSTANT GROUP AND INDIVIDUAL CALLING

The PNC380s Push-to-Talk button initiates instant half-duplex group calling or full duplex individual calling. Supports instant group calling from the HALO Dispatch web-based communications and location tracking application

BUILT-IN WI-FI

Built-in Wi-Fi supports in-building communications with seamless switching to LTE networks when outside Wi-Fi range

HIGH-QUALITY AUDIO

Digital noise suppression and high-volume speakers for excellent voice quality in loud environments. Provides high-quality digital audio performance for individual calls, group calls, and emergency calls

CAR KIT

Dash-mount car kit available for safe in-vehicle calling. Features optional external speaker, palm microphone, visor microphone and remote Bluetooth Push-to-Talk

TFT LCD DISPLAY

TFT LCD display provides high-resolution visibility even in bright daylight. Supports an easy-to-use GUI menu system with clean and simple navigation

LED FLASHLIGHT

Bright LED illumination at the touch of a button

SAFETY FEATURES

One-touch Emergency button enables one-touch emergency calls to dispatcher and sends alarms to other radios

STUN/REVIVE

Dispatcher can remotely stun (disable) or revive (return to service) if the radio is lost or stolen

HIGH-DEFINITION LIVE VIDEO

Equipped with an 8 megapixel rear camera, the PNC380S enables real-time video streaming. Video communications improves situational awareness, and facilitates problem solving and decision making

GPS POSITIONING

Built-in GPS enables real-time tracking and positioning for the Hytera HALO Dispatch application

ERGONOMIC DESIGN

Compact and ergonomic design with easy-access buttons enables comfortable one-hand operation. Reversible belt clip for carrying with screen facing in or out

BUILT-IN BLUETOOTH

Built-in Bluetooth enables connectivity to earpieces, Push-to-Talk devices, and other wireless accessories

RELIABLE AND DURABLE

IP67 rated for protection from dust and water ingress up to 1 meter for 30 minutes. Compliant with MIL-STD-810-G for shock and vibration

LONG-LIFE BATTERY

Powerful 4,000mAh Lithium-Ion Polymer battery delivers up to 24 hours of operation

TEXT MESSAGING

Send, receive, and view text messages between dispatcher and other Hytera PoC devices

Standard Accessories for PNC380S PoC Radio

Audio

POA121

Bluetooth Ring PTT

The wireless PTT ring is designed for finger wearing and allows you to trigger PTT functions without holding a portable radio in your hands.

SM18A3

SM18A3 – Handheld Microphone (designed for connection to Car Kit)

IP67 compliant microphone for CK02

Battery

BP4006

Li-Ion Polymer Battery (4000mAh)

Li-Ion Polymer Battery with 24 hour operating time (4000mAh)

Carrying

RO01

Wrist Strap

Nylon wrist strap

BC50

Belt Clip

Belt Clip for PNC380S

Charger

PS2023

US-Standard Power Adapter

Power Adapter – Input: 100-240VAC, Output: 12VDC/2A

Optional Accessories for PNC380S PoC Radio

Audio

SM09S1

External Speaker for Car Kit

External speaker with clear voice output to be used with Hytera car kits CK02/CK02-E/CK03/CK03-E

SM18A3

SM18A3 – Handheld Microphone (designed for connection to Car Kit)

IP67 compliant microphone for CK02

Battery

BP4006

Li-Ion Polymer Battery (4000mAh)

Li-Ion Polymer Battery with 24 hour operating time (4000mAh)

Charger

PS2023

US-Standard Power Adapter

Power Adapter – Input: 100-240VAC, Output: 12VDC/2A

Carrying

RO01

Wrist Strap

Nylon wrist strap

BC50

Belt Clip

Belt Clip for PNC380S

Car Kit

PS2023

US-Standard Power Adapter

Power Adapter – Input: 100-240VAC, Output: 12VDC/2A

Systems that work with PNC380S PoC Radio

Systems

Hytera HALO Nationwide

Hytera HALO OnSite and OnSite Plus

Own Your Own Push-to-Talk over Cellular System

Hytera HALO Connect

Integrates DMR Radio networks with Push-to-Talk over Cellular and third party networks

HALO PoC Dispatch

Web-based PoC Dispatching Application

Technical Specifications

Network Standards

LTE FDD:B2/B4/B5/B7/B12/B13/B25/B26
WCDMA B1/B2/B4/B5/B8
GSM 850/1900 MHz
WLAN 2.4GHz and 5GHz, 802.11 b/g/n
Bluetooth BT 4.2
Positioning System GPS/A-GPS

General Specifications

Dimensions (H x W x D) 5 27/32” x 2 3/8” x1 1/8” (148 x 60 x 28mm)
Weight (with battery) 208g (with battery)
Memory RAM: 1GB ROM: 8GB
Extended: Micro SD/TF card, up to 32GB
SIM Card Nano SIM 12.3mm x 8.8mm
Display 2.0'' 320×240
TFT/Non-touch
Ports Micro USB 2.0
3.5mm Audio Jack
Dock Charger Interface
CAR KIT Connection Interface
Video and Images Video: 480p @ 30fps for streaming, 720p @ 30fps for recording
Images: 8MP
Operating Voltage 3.85V (Rated)
Battery 4000mAh (Li-ion)
Battery Life ≥24h (5-5-90 working cycle)

Transceiver

Audio Power Output 1W (Rated) (Max: 2W)
Mic Mic with Digital noise suppression

Environmental

Dust and Water Proof IP67 Standard
Shock & Vibration MIL-STD-810 G Standard
Drop Resistance 1.2m
ESD IEC 61000-4-2
±8 kV (Contact)
±12 kV (Air)
Operation Temperature -4F to +140F (-20C to +60C)
Storage Temperature -22F to +158F (-30C to +70C)
