HP50X DMR Two-Way Radio | Hytera Canada

H-Series Professional DMR Two-Way Radio with Optional GPS and Bluetooth

Hytera HP50X series two-way radios are designed with a perfect balance of durability, functionality, and convenience. They are ideal for industries such as construction, manufacturing, and public safety.

The HP50X series radios offer exceptional audio quality and clarity, allowing users to stay connected over long distances. They are also equipped with advanced noise-cancellation technology and powerful speakers.

The Hytera HP50X series two-way radios provide reliable and efficient communication in demanding environments, such as construction sites, public safety operations, and smooth event management.

Data Sheet Owner's Manual Quick Start Guide

Functions

CLEAR AND CRISP AUDIO

Purify your voice, and eliminate the noise. The HP5 Series delivers crystal-clear audio in any environment, thanks to AI-based noise cancellation. This technology suppresses any annoying feedback howling and filters out the unwanted ambient noises. So you can feel like talking face to face in every call no matter where you are.

VERSATILE TYPE-C PORT

Just share the same USB data cable with your smartphone, then you can charge your radio with a power bank or car charger, or program and upgrade your radio. All of these benefit from the universal Type-C port.

LONGER BATTERY LIFE90

The latest in lithium polymer technology is used to power the HP7 Series radios for excellent performance. The battery is light and small, achieving a shift life of 24 hours on high transmit power with a duty cycle of 5/5/90.

ENHANCED GPS LOCATION TRACKING

Location tracking is crucial for personal safety, especially in emergency situations. The HP5 Series provides location updates to the dispatcher, thanks to the optional GPS, BDS, and GLONASS positioning systems. The dispatcher can receive the radio location that is automatically sent with the emergency call, and then allot resources for quick assistance or rescue.

EXTENDED COVERAGE AND CONNECTIVITY

The HP5 extends radio range through increased Tx power efficiency, Rx sensitivity, improved antenna gain, and reduced attenuation. This produces a 25% increase in coverage distance and signal penetration through buildings. The enhanced coverage improves efficiency and reduces network infrastructure costs. Two patented technologies and a voice buffer reduces packet loss during Rx handover for consistently clear calls and fewer dropped words.

BREAK THROUGH THE DISTANCE

When you go further out, you may encounter degraded communications due to weak radio signal. With the 0.18μV (‒122dBm) sensitivity, the HP5 Series provides exceptional communication coverage. It ensures reliable communications even at the far edge of coverage with weak signal. Wherever you go in the workplace, you can always keep connected.

BLUETOOTH CONNECTIVITY AND CONVENIENCE

The HP5 Series has optional BT 5.2 capability, so you can experience total freedom with no cords when using BT audio accessories. This feature also allows you to pair the radio with your smartphone, and then get radio programming done by the HyTool Radio Manager app on your smartphone.

USER-FRIENDLY DESIGN

The HP5 Series has dedicated dual knobs for volume and channel controls, improving your efficiency. The U-shaped slot on the back of the battery allows you to install or remove the belt clip more easily. The enlarged LED indicator makes you know radio status at a glance, no matter whether the radio is in your hand, on your shoulder or waist.

MULTI-SYSTEM OPERATION

The HP5 can be deployed in a wide variety of analog and digital radio networks, including Analog and Digital Conventional, MPT and XPT Trunking, DMR Tier II and Tier III Trunking, IP Multi- Site Connect, and DMR Simulcast Systems

RUGGED RELIABILITY

The HP5 Series is built to withstand the harsh conditions that come with all kinds of industry fieldwork. The radio housing is made of polycarbonate with excellent abrasion and heat resistance. And the texture on the back of the radio is non-slip design. More importantly, this tough radio is IP67-rated and meets stringent MIL-STD-810H military standards for protecting against dust, water, vibrations, 1.5-meter drops, extreme temperatures, and more.

Standard Accessories for HP50X DMR Two-Way Radio

Antenna

AN0155H15

VHF/GPS Antenna (146-164MHz/1575MHz)

VHF Stout Long Antenna, SMA-male, 17cm, 146-164MHz, GPS 1575MHz

Frequency Range	400-470MHz 136-174MHz
Channel Capacity	256
Zone Capacity	16
Channel Spacing	12.5kHz/20kHz/25kHz
Operational Voltage	7.4V (rated)
Battery	1500 mAh Li-ion
Battery Life (5/5/90)	15h (GNSS OFF) 13h (GNSS ON)
Weight	265g
Dimensions (H x W x D)	5 3/16” x 2 5/32” x 1 5/32” (132 x 55 x 29.5mm) without antenna
Frequency Stability	±0.5ppm
Antenna Impedance	50Ω
Display	OLED 0.91” Display
Bluetooth	BT 5.2 BLE+EDR

Time to First Fix Cold Start	<60 Seconds (Typical TTFF)
Time to First Fix Hot Start	<10 Seconds (Typical TTFF)
Horizontal Accuracy	<5 meters Receiver

Digital Sensitivity	0.18μV/BER5%
Analog Sensitivity	0.18μV (12dB SINAD); 0.16μV (Typical) (12dB SINAD)
Adjacent Selectivity	TIA-603: [email protected]; 70dB@20/25kHz ETSI: [email protected]; 70dB@20/25kHz
Spurious Response Rejection	TIA-603: [email protected]/20/25kHz ETSI: [email protected]/20/25kHz
Intermodulation	TIA-603: [email protected]/20/25kHz ETSI: [email protected]/20/25kHz
Hum and Noise	[email protected]; 43dB@20kHz; 45dB@25kHz
Rated Audio Power Output	0.5W
Rated Audio Distortion	≤3%
Audio Response	+1 to -3dB
Conducted Spurious Emission	<-57dBm
Blocking	TIA-603: 80dB ETSI: 84dB

RF Power Output	UHF: 1W/4W VHF: 1W/5W
FM Modulation	[email protected] 14K0F3E@20kHz 16K0F3E@25kHz
4FSK Digital Modulation	12.5kHz Data Only: 7K60FXD, 12.5kHz Data and Voice: 7K60FXW
Conducted/Radiated Emission	-36dBm＜1GHz; -30dBm＞1GHz
Modulation Limiting	±[email protected];±4.0kHz@20kHz; ±5.0kHz@25kHz
FM Hum and Noise	[email protected]; 43dB@20kHz; 45dB@25kHz
Adjacent Channel Power	[email protected]; 70dB@20/25kHz
Audio Response	+1 to -3dB
Audio Distortion	≤3%
Digital Vocoder Type	AMBE+2 /SELP

H-Series Professional DMR Two-Way Radio with Optional GPS and Bluetooth

LIGHTWEIGHT AND COMPACT

LITHIUM POLYMER BATTERY

RUGGED DESIGN

BUILT-IN BLUETOOTH

POWERFUL ANTENNA

360 SMART KNOB

EASY ACCESS EMERGENCY BUTTON

OLED DISPLAY

END TO END ENCRYPTION

AI NOISE SUPPRESSION

WATER PORTING SPEAKER

PUSH-TO-TALK BUTTON

PROGRAMMABLE BUTTONS

VIBRATE MODE

MICRO SD CARD

Functions

CLEAR AND CRISP AUDIO

VERSATILE TYPE-C PORT

LONGER BATTERY LIFE90

ENHANCED GPS LOCATION TRACKING

EXTENDED COVERAGE AND CONNECTIVITY

BREAK THROUGH THE DISTANCE

BLUETOOTH CONNECTIVITY AND CONVENIENCE

USER-FRIENDLY DESIGN

MULTI-SYSTEM OPERATION

RUGGED RELIABILITY

Standard Accessories for HP50X DMR Two-Way Radio

Antenna

AN0155H15

VHF/GPS Antenna (146-164MHz/1575MHz)

Battery

BL1506

1500mAh Li-Ion Battery

Carrying

RO03

Wrist Strap

BC48

Belt Clip

Charger

PS1014

Standard Switching Power Adapter

CH10L27

Single-unit Charger for Li-ion polymer battery

Optional Accessories for HP50X DMR Two-Way Radio

Audio

EHW08

Bluetooth Earpiece with PTT button and microphone

SM27W2

Bluetooth Remote Speaker Mic with charging cable

ESW01

Bluetooth Earpiece with charger(requires PS1030 power adapter)

POA121

Bluetooth Ring PTT

ACN-02

PTT and Microphone cable

ES-01

Earbud without Earpiece (Receive-Only)

ES-02

Earbud with Acoustic Tube (Receive-Only)

EH-01

C-Style Earpiece (Receive-Only)

EH-02

Swivel Style Earpiece (Receive-Only)

EHS17

Swivel Style Earpiece (Receive Only)

EHS18

C-Style Earpiece (Receive Only)

EAS03

Receive-Only Transparent Acoustic Tube Earpiece

EAN21

3-Wire Earpiece with Acoustic Tube, Microphone and PTT (Beige)

EAN24

Earpiece with Acoustic Tube and In-line PTT (Black)

EHN26

C-style Earpiece with In-line PTT and Microphone (Black)

SM26N1

Remote Speaker Microphone (with emergency button)

SM26N2

Remote Speaker Microphone (with emergency button)
